Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 185
Fig. 188. Type Problem. EesertOir Cap. Given Views PREPARATORY INSTRUCTIONS FOR DRAWING PLATE 22 Before starting to draw this plate the student should reviewthe method of drawing tangent lines as described on page 147. … TRACING AND BLUEPRINTING 181 DATA FOR DRAWING PLATE 22 Given: Orthographic drawings, Figs. 190,191,192, and 193. Required: To draw the views of the object shown in Fig.190, 191, 192, or 193, as assigned by the instructor, from thefollowing statements. Any similar problem may be substitutedby the…
Mechanical drawing
