tion opposite to that of be in Fig. 199. The impedance would again ba Z, the e.m.f. would beZ XI, but the current would lead the e.m.f. by the angle 0. Suppose the circuit to contain resistance, inductance, and capacity.The lines of the impedance polygon would then be laid off as in Fig. 201.The…
