. above the atmosphere. It has long been obsolete. Horse-power Constant of a given Engine for Varying Speeds =product of its area of piston and length of stroke divided by 33,000.This multiplied by the mean effective pressure and by the number ofsingle strokes per minute is the indicated… … Fig. 156.curve first having drawn OX parallel to the atmospheric line and 14.7lbs. below. Measure from a the distance ad, equal to cb, and draw YOperpendicular to OX through d; then will TB divided by AT be the per-centage of clearance. The clearance may also be found from the expan-sion-line by…
