The mechanical engineering of power plants (1897)

Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 130

An illustration from The mechanical engineering of power plants, 1897, leaf 130
ident an excess of water hascome within the skin of the vessel, so that the propellingengine can be used to empty the bilges and lighten the dutyof the bilge-pumps proper. It will be seen that the injectiondescends across the exhaust-steam in a finely divided shower,whereby the least weight of…

Mechanical engineering · Steam power plants

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
