Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 266
Fig. 191. … Fig. 192. 230 MECHANICAL ENGINEERING OF POWER PLANTS. gear, shown in Fig. 191 as applied to a marine engine, andin Fig. 192 in outline. It has been used quite a little inboth marine and locomotive service. It will be seen that themotion originates from a point on the connecting-rod whichgives from…
Mechanical engineering · Steam power plants
