The mechanical engineering of power plants (1897)

Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 306

An illustration from The mechanical engineering of power plants, 1897, leaf 306 — ENGINE FOUNDATIONS AND BED-PLATES. 269 horizontal plane. Fig. 226 represents a standard bed-plateof this type, and Fig. 227 shows a section through the girder(see Fig. 182 also). A modification of the Corliss bed-plate is identified withthe name of Tangye of England, in which the cylinder… … Fig. 227. mass around the guides, and the crank end is moulded witheasy curves to clear the space required for the motion of thecrank and connecting-rod. Fig. 228 may stand for this designas well as Figs. 92, 95, and others. The advantage of theTangye (sometimes also called the Porter) bed-plate is…

Mechanical engineering · Steam power plants

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
