swG cicmncH 48 MECHANICAL ENGINEERING OF POWER PLANTS, permits the straight descent of the plunger-rods, it can readily^be seen that a successful design could as easily have beenmade by having the cylinders vertical and attached to a … longer beam, leaving space nearer the centre for the attach-ment of the plunger-rods, and one on each side could havebeen used. It is an advantage to give a long stroke to thesteam-cylinder to secure high piston-speed. THE MECHANISM OF ENGINES. 49 Fig. 33 shows a modern type of beam-engine in…
