Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 183
Fig. 90. … Fig. 99.that of the clearances in each cylinder. The diagrams shouldbe placed one over the other, so that these lines representinga zero clearance volume shall coincide. (Fig. 90.) SIMPLE AND COMPOUND ENGINES. 131 In a triple- or multiple-expansion engine where the ex-pansion is in three or more…
Mechanical engineering · Steam power plants
