Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 287
Fig. 196. 123. Allen Link-motion.—The link-motion first proposedby Allen is the one which in a modified form is known as the REVERSING VALVE-GEARS. LINK-MOTIONS. 2$$ Pius Fink gear. It has no eccentric-rod properly so called,but the link is an integral part of the back strap. Thehalf of the strap…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
