The watchmakers' lathe, its use and abuse; a story of the lathe in its various forms, past and present, its construction and proper uses (1903)
Goodrich, Ward L. [from old catalog] · Chicago, Hazlitt & Walker · leaf 18
in the highest terms. Fig. 8illustrates this lathe ready for work. Like the turns, it isheld in the vise, but, unlike it, motion is imparted to thework by means of a hand wheel and catgut cord. The righthand runner is precisely the same as used in the turns butthe left hand one is pierced through… … Fig. 9. Dracip Lathe Ready for Drilling. means of a cord. Now as this loose pulley is rotated, it alsorotates the smaller runner by means of the pin, which, stick-ing out of the body of the latter, projects between the twodriving pins and this runner imparts motion to the work bymeans of the dog…
Clocks and watches · Lathes
