Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 319
a spherical casinghangs vertically, and all steam-openings coincide so as toleave free passage from boiler to engine. As the ship pitches 264 MECHANICAL ENGINEERING OF POWER PLANTS. it changes the angle of the steam-pipe, to which a fixed casing isattached, while the pendulum-ball remains vertical.… … Fig. 219.can get through. The pendulum swings steam-tight by meansof flexible or spherical joints at the opening through which itprotrudes. Most engineers even with such a governor attachedto their engines do not relax their vigilance at the throttle. 148. Connections of the Governor to Control…
Mechanical engineering · Steam power plants
