ecylinder an inner lining which fits in properly preparedshoulders or flanges in the outer casing which forms thejacket. The joint between the lining and the rest of the cast-ing is made by copper rings. The cylinder-cover closes downupon this lining to prevent displacement. The other plan is,not… … LEAVITT JOINT. CORLISS JOINT-. Fig. 234.Outside of the jacket, or protecting the cylinder-castingproper if there is no jacket, is a provision for some non-con-ducting material. This may be hair-felt, mineral wool, orwood, or combinations of these with asbestos board. Thisnon-conducting material may…
