drainage-connection may remove any entrained waterwhich may be carried through neck or nozzle by high velocityof steam-currents. Fig. 367 will .illustrate this arrangementwhen the drum is transverse, and is really a large pipe merelyjointed to each boiler by piping which allows of expansionwithout… … TYPES OF BOILERS. 431 ment-surface to pass into the steam-pipe through a numberof small holes in the interior pipe which is a prolongation ofthe steam-pipe inside the boiler. The gentle current intoeach opening prevents entrainment of water, because theaggregate area of openings is in excess of the…
