int marked release in its travel to the right. A.t this time the inside edge of valve D has reached the inside edge of the steam port Pr, asshown on diagram C, and the expanded steam begins to flow from the cylinder into the ex-haust port J which communicates with the atmosphere, a condenser or a… … STEAM ENGINES 231 piston, having reached the end of its stroke to the right, has its motion reversed; the motion ofthe valve, however, is not reversed until a somewhat later period. The expanded steam is forcedout of the cylinder until the piston has reached a point in the return stroke marked…
