Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 263

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 263
ecuts, and the specimen cutshows a few of the designsthat such a machine is ca-pable of producing. Thefj sectional head contains theclamp device for holding thework. The tool U mayhave from one to four pointslike a chasing tool to varythe design of the work. His the work in the chuck andR the cam… … /HOLLOW DRAW IN 3PIN0LE/CONE / , BEARING

Mechanical movements
