emams in each case the absolute velocity of exit from the blades which carries away — ft.-lb. of work per lb. of steam STEAM TURBINES 313 supplied, and in addition there is the loss due to friction. Let AB represent the heat available forthe first pressure stage. If the length of the segment AF… … Fig. 18. Curtis Turbine—Few Pressure Stages—Two Fig. 19. Rateau Turbine—Multiple-Pres-Velocity Stages for Each Pressure Stage. sure Stages—Single-Velocity Stage. This heat, except for a small fraction that is radiated, is expended in raising the quality of thesteam (or superheating it). The quaUty…
