Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 556
, owing to the layout of the engine room in reference to the boilers, the loop system (Fig. 9)may be used to advantage with very little extra expense. The Spider System. This system (Fig. 3) represents good practice in many small plants.The boiler leads, in this arrangement, are connected to a… … ^By-pass-.Automatic Non ReturnStop valve, -S3- Steam Nozzleof Boiler, 3-E- Y Method of drainingSieam Header To Trap__£
Building · Heating · Ventilation
