Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 636
(a) Cylindrical Tank. … (6) Steel-Plate Sus-pension Bunker. (c) Steel-Plate, Con-crete Lined Sus-pension Bunker. (d) Suspended SteelStraps, ReinforcedConcrete Lining. (e) Structural SteelSkeleton, ReinforcedConcrete Lining,Longitudinal GirderType. (/) Similar to (e), butof the Cross-GirderType. (g) Same as (/). Fig. 4.…Building · Heating · Ventilation
