Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 759
440 1,920 2,880 3,840 5,760 7,680 2,300 4,600 3,200 6,400 9,600 12,800 19,200 25,600 38,400 51,200 Double-Pipe Ammonia Condensers. These condensers are usually made twelve pipes high,some builders use ten. The three upper pipes are 2¥> inches in diameter, and the nine lower 02 POWKR PLANTS AND… … Fig. 2. Standard Type Double-Pipe Ammonia Condenser. face of the ammonia pipe, and thus provides the greater space which is required for the gas whenit first comes into the condenser, owing to its rarefied condition. As soon as the cooling influenceof the water becomes effective and the ammonia…
Building · Heating · Ventilation
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
