Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 341
Fig. 4. Sectional View of Peck-Williamson Underfeed Ftrnace. 322 HEATING AND VENTILATION by using a double wall slack (Figs. 10, 11 and 12), in which there is an air space between the insideand outside pipes, and no asbestos covering is used. See Table 6 of this equipment, as madeby the Excelsior… … Fig. 5.Vertical Stack with Side Wall Register. Fig. 6.Vertical Stack with Register in Upper Floor. THE DESIGN OF A FURNACE HEATING SYSTEMHeat Loss and Air Required. The determination of the size of the furnace, and the con-necting leaders, stacks, registers, ducts, etc., is based on: (1) The actual…
Building · Heating · Ventilation
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
