Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 35
DETAIL OF WINDOW FRAMING INTO CONCRETE LINTEL BEAM. … DETAILS OF CONNECTIONS FOR CONCRETR GIRDERS FRAMINGINTO STEEL COLUMNS. Plate 1—Cemknt Constuuction. CEMENT CONSTRUCTION 17 A short tie-rod can be used by the following method:The top flanges of the two joists should be broken awayfor about 6 feet next to the wall. In this space, lay a tie-rod about…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
