Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 429
Fig. 15. Koerting Multi-JetEductor Condenser. Fig. 16. Method of Installing Koerting Multi-Jet Eductor Condenser.A Condenser; B. Water Check Valve; C, Free Exhaust Valve- D, Stramer; E, Foot Elbow; S, Stand Pipe. capacity, but, in spite of this, the area of contact between the steam and the water… … Figs. 17 and 18. Installation of Bulkley Barometric Condenser. STEAM CONDENSERS 401 A further advantage is gained by the form of the condensing tube, which in vertical section isan inverted cone. In the upper part of the tube the steam is in contact with the coldest water,and condensation is…
