Mechanical laboratory methods; a testing of instruments and machines in the mechanical engineering laboratory and in practice (1918)
Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 68
Fig. 30.—Flather Dynamometer. The fluid pressure* thus produced is transmitted through tubes,t, and a longitudinal hole through the center of the driver shaft.Connecting with this hole at the end of the shaft is an indicatorby which a graphic record of the pressure is made. Since thispressure is…
Mechanical engineering laboratories
