Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 151

An illustration from Mechanical movements, powers and devices, 1911, leaf 151 — 505. DEAN STEAMPUMP.—The valve gearof the Duplex pump. Alever and rock shaft, movedby a spool on the connect-ing rod, operates the valveof the opposite cylinder, for alternating the strokes of the pistcns. I40 HYDRAULIC POWER AND DEVICES. r^ … 506. WORTHINGTONDUPLEX PUMP. — Tworock shafts with arms movedby the opposite piston rodalternate the valve motionsand strokes. The water pis-ton is of the plunger form. 507. HALF-YOKE CONNECTION forpump piston rods with central crank. 508. The centre crank.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
