Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 194
rs throughone of the handles with its flow controlledby a lever and valve. The^ exhaust enters the case fromthe port in the oscillating cyl-inder trunnions. The threedouble-acting pistons are di-rectly connected to cranks andpinions which mesh with aninternal spur gear, which is fastto the outer…
Mechanical movements
