711. MULTIPLE BRUSH COM-MUTATOR.—The brushes are adjust-able on the pivots of the handle bar, andare given an even pressure on the com-mutator by springs. 712. Front view. ELECTRIC POWER AND CONSTRUCTION. 191 … 713. BIPOLAR SHUNT GEN-ERATOR, showing the shunt wind-ing on both fields and its connectionto the brushes, with interveningrheostat controller.
Mechanical movements
