Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 202
713. BIPOLAR SHUNT GEN-ERATOR, showing the shunt wind-ing on both fields and its connectionto the brushes, with interveningrheostat controller. … 714. FOUR-POLE COM.POUND GENERATOR, show-ing shunt winding and rheostatconnection. Wiring is successiveon each pole in the oppositedirection for both shunt andcurrent.
Mechanical movements
