Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 259
984. HIGH-SPEED EPICYCLIC TRAIN.— Bevel gear C is the driver; m / is a fixedshaft. Bevel pinion D and spur gear E are fixedon a hollow shaft. Bevel pinion A and spur gearH are fixed on a hollow shaft, revolving on thehollow shaft I. The arm m n revolves freely onthe fixed shaft m p. The spur wheels…
Mechanical movements
