ed from thegrain and carried off through the fan;S, lifting pipe of conical form; N,regulator with a rubber diaphragm toallow the foot nozzle O to regulatethe proportion of air and grain. Atthe bottom of the receiver R is a coni-cal valve to discharge the grain whenit overbalances the weights.… … SIDE ELEVATION Section XII. MOTION AND DEVICES CONTROLLING MOTION. RATCHETS AND PAWLS, CAMS, CRANKS, INTERMITTENT AND STOP MOTIONS, WIPERS, VOLUTE CAMS, VARIABLE CRANKS, UNIVERSAL SHAFT COUPLINGS, GYROSCOPE, ETC.
