Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 287

An illustration from Mechanical movements, powers and devices, 1911, leaf 287 — 1126. VARIABLE CRANK THROW.—The jointed crank and radial screw give=^ a large variation to the throw of a crank. 1127. COMBINATIONCRANK-MOTIONCURVES.—A revolving6 crank A, D and the vi-brating link B, E carry-ing an extended connect-ing arm with a pencil atthe end F. A great variety of figures and…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
