Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 326

An illustration from Mechanical movements, powers and devices, 1911, leaf 326 — 1271. ADJUSTABLE HANGER for shafting.A, drop of the hanger. Jointed cap to allow ofremoval of shaft. 1272. SCREW TRAVERSINGBALL BEARING, with balls returningthrough outside passage. Grooves re-cessed in shaft. … 1273. SCREW TRAVERSINGBALL BEARING. The balls returningby a side passage. Ball grooves enlargedfor full strength of shaft. 1274. HANGING SHAFT on ball bearings. 1275. SUSPENDED SHAFT on ball bearings. 1276. CURVED STEP BEARING, with oOreservoir. 3i6 MILL AND FACTORY APPLIANCES.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
