Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 327
1273. SCREW TRAVERSINGBALL BEARING. The balls returningby a side passage. Ball grooves enlargedfor full strength of shaft. 1274. HANGING SHAFT on ball bearings. 1275. SUSPENDED SHAFT on ball bearings. 1276. CURVED STEP BEARING, with oOreservoir. 3i6 MILL AND FACTORY APPLIANCES. … 1277. CONICAL PIVOT BEARING and adjust-ing screw. 1278. LUBRICATION OF A HANGINaBEARING by hydraulic pressure. Oil isforced into the grooves of the bearing throughthe small holes and discharges into the cuparound the outside. 1279. VERTICAL SHAFT STEP.—Madeadjustable by a movable bearing held by…
Mechanical movements
