Mechanical movements, powers and devices (1911)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 327

An illustration from Mechanical movements, powers and devices, 1911, leaf 327 — 1277. CONICAL PIVOT BEARING and adjust-ing screw. 1278. LUBRICATION OF A HANGINaBEARING by hydraulic pressure. Oil isforced into the grooves of the bearing throughthe small holes and discharges into the cuparound the outside. 1279. VERTICAL SHAFT STEP.—Madeadjustable by a movable bearing held by… … 1280. SHAFT STEP ADJUSTMENT forspindles of millstones. 1281. ADJUSTABLE STEP BEARING,with hard bronze bush and step. A mor-tise through the iron base and a key drawn,with a screw extension and nut are for verti-cal adjustment.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
