37. Four and three sheave blocks, with end of ropefixed to top block. Four sheave block fixed, threesheave block movable. P = W Vv = P X 6. … r ^S. Roving of a three and two sheave pair ofblocks, with a draw block fixed above. P = W -^. W = P X 6,o THE MECHANICAL POWERS. 25
