Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 113
ZJ\h. THE WORTHING-TON WATER TUBEBOILER.—The water tubesections are between headersand cross each other in series;the lower ends of the diagonalsections are connected with across pipe for circulation fromthe steam drum. Has theAmerican stoker attached. … 3712. VAUCLAINS COM-POUND LOCOMOTIVECYLINDERS.—A single pis-ton valve for both cylinderswith direct steam passagesthrough the valve chamber.High pressure steam entersat the central port A. Steaminlet and exhaust indicated bythe arrows. Section V^. STEAM APPLIANCES. Injectors, Steam Pumps,…
Mechanical movements
