Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 136
making air gas fromgasoline; non-freezing. A,plan — a zig-zag series ofchambers with spaces be-2% tween for air circulation tokeep its vaporizing wallswarm; B, a vertical section; c, c, c, open spaces. Canton or otherflannel wrapped over wire gauze frames is pushed into the longi-tudinal spaces… … 448. AUTOMATIC OILER.—Much inuse on explosive motors. Shaft r, andcranky, with the dip wire d, are revolved bya belt dropping the oil on the wiper e, intothe small tank/, from which it flows to thecylinder.
Mechanical movements
