8800-. SHIPS STEER-ING GEAR.—A slottedcross head fixed to the rud-der post, in the slot ofwhich two nut bearingstraverse; the nuts beingcarried in opposite direc-tions by right and left-handscrews operated by thesteering wheel and gears. 228 NAVIGATION AND ROADS. … 88o/z. STREET CLEAN-ING MACHINE. — A re-volving brush A, driven bylink belt from the wagonwheel, throws the dirtupon the ele-vator B, and mXUJJ 11 IIJ I M lilUUiiXUI.11 11 I.LIE in the box D. E, the distributer; F, water tank to supply the sprinkler G.
