Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 253
ALTERNATING RECTILINEARMOTION by the revolution of a sec-tor by which one revolution producesboth motions. The curved back ofthe sector just touches the extendedtooth of the rack frame at ^/, while the teeth at e and b are partly inmesh with the enlarged sector end teeth, thus preventing…
Mechanical movements
