Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 329
ANGLE SHAFT COUPLING, Robes patent. The shaft headsare slotted, in which cross barsare pivoted; the ends of the crossbars are also pivoted to the armsof the double yoke, giving a freemotion to the driven shaft at anyangle greater than a right angle. … 1294. UNIVERSALshafting. Ring gimbaL JOINT, for 95. HOOKES UNIVERSAL JOINT.—One shaft end is keyed into a ball with trun-nions, which turn in a ring with trunnions atright angles with the ball trunnions. The ringtrunnions turn in the outer shell to which theother shaft is keyed. MILL AND FACTORY…
Mechanical movements
