to hold sufficientwater for making steam,which should be at 75pounds pressure. Com-pression is made by thelever and weight for bothtires and bands. A gas orgasoline torch for heating. 14430-. RIGHT ANGLE SHAFTTRANSMISSION.—A bell cranksliding on a cross bar is pivoted at itsends to the crank pins… … 1443/?. TAKE-UP AND LET-OFF MOTION FOR LOOMS. —The detailed parts are:Take-up roller I, let-ofT rol-ler K, a pawl U pivoted tothe vibrating lever V operatedby the shuttleboard frameG, H, and moving the ratchetT, bevel gear S, S, shaft P,worm gear R, R, and gearconnection to move the rollersI, K. E,…
