Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 387
. WIRE-DRAWING MACHINE. <T, the reel. ^, draw plate. r, power drum, operated by gearbeneath the bench. When the wireis all wound on the drum it ischanged to the reel and drawn ina reverse direction. … 1558. WIRE-COVERING MACHINE. —The wire is passed through a hollow re-volving spindle <2, having a small longitu-dinal motion from a vibrating cam to lapthe threads. The face plate revolving withthe spindle carries two or more spools, <:, c,with guide eyes, d, //, vibrating with thespindle.…
Mechanical movements
