51. ECCENTRIC CRANK and Treadle.—Abelt over the eccentric and a roller in the treadle.The equivalent of a crank. 52. CAPSTAN, OR VERTICAL WIND-LASS.—The pawi falling in the circular rackat the bottom locks the windlass. The ropeshould always wind on the bottom and slipupward. … 53. STEERING GEAR.—A hand wheel anddrum on a shaft, carrying a rope rove throughguide pulleys and attached to the tiller. 54. JUMPING MOTION given to a weight,or other body, by a pin wheel and bell-cranklever. 30 TRANSMISSION OF POWER, ^ 7^ 55. ROPE SPROCKET WHEEL, several modi-ficatrons of which…
