d-ing block pivoted to the engineframe. 138m. REVERSEMOTIONDRIVE.~A beingthe driving pulley,B a driven pulley,will have a reversemotion by the beltrunning on thenear side guidedby the two idlerpulleys.138W. INTERMIT-TENT TRANSMISSIONJ power by spur gear. A is thedriver. When B and C are to-gear F…
