Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 128

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 128
421/. FLEXIBLE METALLIC TUB-ING.—The corrugations are deep indentedrings spun or pressed from a plain tube.It may be also made spiral. Section VI. MOTIVE POWER. Gas and Gasoline Engines, Valve Geaf and Appliances, Connecting Rods and Heads. … «? 422. GASOLINE ENGINE, Olds model. Plan showinglocation of valve chest and valve gear, operated from an eccentric withan alternating sector gear for an impulse at every other revolution.
