Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 128
«? 422. GASOLINE ENGINE, Olds model. Plan showinglocation of valve chest and valve gear, operated from an eccentric withan alternating sector gear for an impulse at every other revolution. … 423. SECTIONAL PLAN OF A GASOLINE ENGINK—Four-cycle type, with exhaust port opened by the piston at the endof the stroke, and continued exhaust through an annular valve aroundthe inlet valve. The charge is heated and vaporized in the valv<^chamber by the exhaust. * Olin model. MOTIVE POWER.
Mechanical movements
