Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 141
463-0-. JUMP SPARKCOIL for gas and gaso-line engines.—^H, H,iron wire core; P, pri-mary coil; S, secondarycoil; L, condenser; D,spark breaker; A, bat-tery ; J, switch; P, M,binding posts. i.^o MOTIVE POWER, … 463/L CALORIC ENGINE, Erics-son Model.—d, d, the cylinder inwhich the transfer piston moves withspace between it and the cylinder toallow the air to be quickly transferredfrom the hot end to the cool end andvice versa. h. Impulse piston attached directlyto the walking beam. The transferpiston is…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
