Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 180

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 180
630. ROOT ROTARY BLOWER. An early form. Has been also usedas a pump. … 631. ROOT ROTARY BLOWER. —Present design. The extended sur-face of the periphery of the wheels al-lows them to run loosely in the shellwithout friction, and with very smallloss by air leakage. 17© AIR POWER APPLIANCES. 632. HYDRAULIC AIR COM-PRESSOR.—A reciprocating piston inthe water cylinder, G,…
