656. CRANK EQUALIZ-ING ANGLE in air com-pression. The cylinders areset at an angle of 135^. Davies system in England :-*i-~>^ji i ^^+t- 1 … 657. CRANK EQUALIZING AN-GLE in air compression. Used toequalize the mean pressure of thesteam and air pistons. The cylindersare set at an angle of 45° . Waringand Rand system.
