Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 203

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 203
719. FLEXIBLE COUPLING for engine and generator directconnection. 720. Plan. The Zodel coup-ling. A flange on each shaftwith overhanging crowns inter-lapping. A continuous belt overthe outside and under the insidecrowns allows of considerable variation in alignment and longitudinalvibration in the… … I. CAR TRUCK MOTORS. — Direct - connected electricmotors on street-car axles. ELECTRIC POWER AND CONSTRUCTION. i93

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
