777. FULL SCHOONER RIG—Main- and fore-sail, two or three jibs,and two topsails, i, flying-jib ; 2, jib:3, foretop staysail; 4, foresail; 5, maift-sail; 12, fore gaff-topsail; 13, maingaff-topsail. … 778. TOPSAIL SCHOONER. —Thesame rig as a schooner, except the foretop,which is a square sail bent to a yard, i,flying-jib; 2,jib; 4, foresail; 5, mainsail;9, fore-topsail; 13, main gaff-topsail. .779. CLUB TOPSAIL RIG.—In additionto the full schooner rig, a club topsail is bentto a stay from the…
